Medium-Power Laser Cleaning Machine

Medium-Power Laser Cleaning Machine

Description

The application scope includes: component bonding, welding surface pretreatment, metal surface paint removal (full surface paint removal or specified part paint removal), and cleaning of various industrial products or molds.

Price: $
Product Introduction

RQM-0500 operating system; The system is mobile and durable; Based on microcontroller control system (menu driven); The RQM-0500 laser safety protection level four is a medium power laser cleaning equipment, mainly used for paint removal of industrial products and cleaning of high-value components. Powerful power not only does not damage the object being cleaned, but also does not pollute the environment. The design of each configuration has sustained and stable performance, making it almost maintenance free. Easy to install, operate, and automate. Plug in the socket and turn on the device to perform cleaning without chemical reagents, media, dust, or water.

Industry Applications

Mainly used for paint removal of industrial products and cleaning of high-value components. Powerful power not only does not damage the object being cleaned, but also does not pollute the environment.Component assembly, welding surface pretreatment, metal surface paint removal (full surface paint removal or specified part paint removal), and cleaning of various industrial products or molds.

Technical Parameter
Model No RQM-0200 RQM-0300 RQM-0400
Cleaning width 0-80mm(Customizable) 0-80mm(Customizable) 0-60mm(Customizable)
Laser power 200W 300W 400W
Wavelength 1064±5nm 1064±5nm 1064±5nm
Applicable materials Metal surface Metal surface Metal surface
Pulse frequency 2-50KHZ 2-50KHZ 2-50KHZ
Cleaning speed 5-10m2/h 7-12m2/h 10-20m2/h
Scanning speed ≤6000mm/s ≤6000mm/s ≤6000mm/s
Power ≤3000W ≤3200W ≤4000W
Positioning accuracy ±0.03mm ±0.03mm ±0.03mm
Repeatability ±0.02mm/m ±0.02mm/m ±0.02mm/m
Cooling method water-cooling water-cooling water-cooling
Power demand AC220V AC220V AC220V
×
